Specifications:

• Pressure: Medium Pressure
• Pressure environment: Atmospheric pressure
• Power: Stepper motor
• Power Source: AC
• Port Size: DN15 DN20 DN25 DN32 DN40 DN50
• Port Size: 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
• Model Number: SEV3000
• Media: Water
• form: Ball type
• Flow direction: two-way
• Driving method: Electronics
• Connection form: Internal screw thread
• Applicable medium: water
• Actuator Mode: Without Manual And Instruction
• 3C valve category: Industry
• working temperature: normal atmospheric temperature
• uses: temperature control
• Certification: CE
• Material: BRASS
• Origin: CN(Origin)
• Type (channel position): Two general formula
• Texture of material: brass
• Temperature of Media: Medium Temperature
• Structure: Ball
• structural style: Float ball valve
• Standard or Nonstandard: Standard
• standard: National standard
• Specifications: Actuator (Torsion 4.5 nm)
• Spare parts and accessories: Actuator
